In the fields of building construction, road and bridge construction, mineral exploration, and environmental monitoring, the accuracy of foundation bearing capacity and soil density data directly determines project safety. The SPT rig (Standard Penetration Test Rig) is one of the most frequently used in-situ testing devices in the world. It obtains the soil blow count (N value) through standardized hammering methods, providing reliable data support for foundation design, pile selection, and foundation treatment. SPT rigs have several common names in the international market: standard penetration test drilling rig, soil testing drilling rig, geotechnical drilling rig, soil sample drill rig, and dynamic probing rig. In the African market, they are often referred to as “SPT machine” or “N-value testing equipment,” while Southeast Asian engineering teams typically call them “soil investigation rig” or “borehole SPT rig.” Some users also refer to them alongside core drilling rigs or fully hydraulic core drilling rigs, as modern SPT rigs usually combine standard penetration testing and core sampling functions. Regardless of the name, their core function is to obtain soil penetration resistance values and undisturbed soil samples through standardized hammer impact energy. The YG series SPT rig adopts a fully hydraulic drive system, supporting both soil sampling and core drilling modes, and has been successfully delivered to many countries and regions in Mexico, Africa, and Southeast Asia. If your project also needs an SPT rig, please contact us for more product information.
Hot-sale YG SPT Rig Technical Parameter
| Model | YGX-400 | YGX-600 | YGX-800 | YGX-1000 |
| Drilling Depth(M) | 180-400-500 | 200-600-650 | 400-800-1000 | 500-1000-1100 |
| Rated pressure(MPA) | 21 | 21 | 25 | 28 |
| Rated Flow(L/min) | 168 | 192 | 260 | 300 |
| Heat Dissipation Mode | Air cooling+water cooling | |||
| Engine Brand | Yuchai | Yuchai | Yuchai | Cummins |
| Rated power/speed | 78kW/ 2400r/min | 92kW/ 2400r/min | 92kW/ 2400r/min | 154kW/2400r/min |
| Drilling Angle(°) | 0-90 | 45-90 | 45-90 | 45-90 |
| Lifting Force(T) | 12 | 16 | 24 | 30 |
| Feed Force(T) | 6 | 8 | 12 | 15 |
| Hydraulic Mud pump flow | 30-90（L/min） | 30-90（L/min） | 90-180（L/min） | 90-180（L/min） |
| Hydraulic Mud pump power | 4-7(MPA) | 4-7(MPA) | 4-7(MPA) | 4-7(MPA) |
| Dimension | 4000*1900*1800mm | 4000*2000*1800mm | 5500*2100*2000mm | 6000*2200*2400mm |
| Weight | 4.3T | 4.5/5.5T | 6.5T | 7.5T |
