Mortar Spraying Machine

Mortar spraying machine is a mechanical device used to spray mortar onto walls, ceilings, or other surfaces quickly and evenly. It usually loads the mixed mortar through a hopper and then transports the mortar to the spray gun through a pumping system. The operator uses the spray gun to spray the mortar onto the target area. This machine can significantly improve construction efficiency, reduce manual labor intensity, and ensure the uniformity and quality of the mortar coating. It is widely used in construction projects, indoor and outdoor wall plastering, tunnel lining, renovation of old buildings, and other fields. Contact us for the latest product information and prices.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800

Request A Quote

Electric and Diesel Mortar Spraying Machine Parameter:

Type Electric Diesel
Output 3m³/h 4m³/h
Power 220v-380v/7.5kw Diesel
Pressure 3Mpa 3Mpa
Conveying tube 32mm 32mm
Max. Aggregate size ≤8mm ≤8mm
Hopper volume 80L 80L
Air consumption 0.3m³/min 0.3m³/min
Weight 320kg 320kg
Applicable material proportion 1:1:3
Conveying distance Horizontal:50m  Vertical:30m Horizontal:50m  Vertical:30m

Request A Quote

Working Principle of Mortar Spraying Machine:

  1. Pour the mixed mortar into the hopper.
  2. Start the machine, the pumping system starts working and sucks the mortar in the hopper into the pump body.
  3. The pumping system pressurizes the mortar and delivers it to the spray gun through the delivery pipeline.
  4. The operator holds the spray gun and sprays the mortar onto the wall in a mist form by controlling the valve at the nozzle.
  5. The spraying pressure and flow can be adjusted by the control system to achieve the best spraying effect.

YG High-Efficiency Mortar Sprayer Features:

  1. High-efficiency spraying: The spraying speed is fast, and the efficiency is several times that of traditional manual plastering, which greatly shortens the construction period.
  2. Uniform spraying: Mechanized spraying ensures the uniformity of the thickness of the mortar layer and improves the flatness and aesthetics of the wall.
  3. Save materials: By controlling the spraying amount, the waste of mortar is reduced.
  4. Reduced labor intensity: Liberate workers from the heavy manual plastering work and reduce labor intensity.
  5. Adapt to a variety of mortars: It can spray ordinary mortar, cement mortar, putty, fire retardant coatings, and other materials.
  6. Easy to operate: The machine is humanized in design, easy to learn and operate, and easy to maintain.
  7. Strong adjustability: The spraying pressure, speed, and flow rate can be adjusted to meet different construction needs.

Request A Quote

Applications and Feedback from Different Customers Using Mortar Spraying Machines:

Case 1: Exterior wall plastering project of a large residential project in Florida, USA

“Our company has undertaken a large residential development project in Florida, USA, which requires a lot of exterior wall plastering work. Previously, we have been using traditional manual plastering methods, which is not only inefficient but also difficult to ensure that the wall quality of each building meets the uniform standard. At the recommendation of a friend, we tried using YG’s mortar sprayer. The result is very surprising! The spraying efficiency of one machine is equivalent to that of several of our skilled workers working at the same time, which greatly shortens our construction period. More importantly, the sprayed wall surface is very flat and uniform, and almost no later repairs are required. Our customers are very satisfied with the final quality. Now, we have decided to use YG’s mortar sprayer as the standard equipment for our company’s exterior wall plastering.” – Michael Johnson Johnson, Project Manager of a Construction Company in Florida, USA

Case 2: Interior Wall Renovation Project of Old Buildings in Central London, UK

“I run a small decoration company in central London and often need to renovate the interior walls of old buildings. The walls of these buildings are often uneven and require spraying of different types of mortar and putty. Since I bought YG’s mortar sprayer, my work has become much easier. This machine is not only easy to operate but also can adjust the pressure and flow of spraying according to different materials, and the spraying effect is very delicate. In the past, we needed to spend a lot of time and energy to manually scrape putty, but now we can use a sprayer to complete it quickly and with better results. My customers are very satisfied with the renovated walls, which has won us more reputation and business.” – Sarah Williams, head of a decoration company in London, UK

Request A Quote

Mortar Spraying Machine for Sale – YG Machinery

In summary, the YG high-efficiency mortar sprayer has become an indispensable tool in modern construction with its excellent performance, including efficient spraying speed, uniform coating effect, and significant labor and material cost savings. Whether it is interior and exterior wall plastering of large-scale construction projects or wall treatment of small-scale decoration projects, this equipment can provide efficient, convenient, and high-quality solutions. Contact us now to purchase a mortar sprayer.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
