Accurate and efficient core drilling is essential in mining, geological exploration, and construction projects. The full hydraulic core drilling rig mainly comprises a hydraulic power unit, a drill mast, a rotary head, a feed mechanism, and a core barrel. It has been sold to Cambodia, the United States, Mexico, and other countries, and has received good feedback from customers. The hydraulic core drilling rig is a good helper to improve efficiency. If you also want to get more information, please contact us now.【WhatsApp/WeChat/Skype/Phone】+86 136 1385 6800
Full Hydraulic Core Drilling Rig Parameter:
| Model | YGX-400 | YGX-600 | YGX-800 | YGX-1000 |
| Drilling Depth(M) | 180-400-500 | 200-600-650 | 400-800-1000 | 500-1000-1100 |
| Rated pressure(MPA) | 21 | 21 | 25 | 28 |
| Rated Flow(L/min) | 168 | 192 | 260 | 300 |
| Heat Dissipation Mode | Air cooling+water cooling | |||
| Engine Brand | Yuchai | Yuchai | Yuchai | Cummins |
| Rated power/speed | 78kW/ 2400r/min | 92kW/ 2400r/min | 92kW/ 2400r/min | 154kW/ 2400r/min |
| Drilling Angle(°) | 0-90 | 45-90 | 45-90 | 45-90 |
| Lifting Force(T) | 12 | 16 | 24 | 30 |
| Feed Force(T) | 6 | 8 | 12 | 15 |
| Hydraulic Mud pump flow | 30-90（L/min） | 30-90（L/min） | 90-180（L/min） | 90-180（L/min） |
| Hydraulic Mud pump power | 4-7(MPA) | 4-7(MPA) | 4-7(MPA) | 4-7(MPA) |
| Dimension | 4000*1900*1800mm | 4000*2000*1800mm | 5500*2100*2000mm | 6000*2200*2400mm |
| Weight | 4.3T | 4.5/5.5T | 6.5T | 7.5T |
YG Brand Hydraulic Drilling Rig Applications & Use Cases:
- Mineral Resource Exploration: In the exploration of mineral resources such as metal mines, coal mines, and non-ferrous metal mines, core drilling machines for mining can be used for deep hole coring to obtain rock and mineral samples deep in the stratum, providing the key basis for mineral resource reserve assessment and mining plan formulation. [Case: A large coal mining enterprise uses for deep exploration of ore veins and successfully explores new high-quality coal seams, providing strong support for mine expansion and efficiency improvement. ]
- Engineering geological survey: Before the construction of foundation projects such as high-rise buildings, bridges, tunnels, and water conservancy projects, can be used for engineering geological surveys to identify stratum structure, lithology characteristics, geological structure, and hydrogeological conditions, providing accurate geological parameters for engineering design and construction. [Case: A cross-sea bridge project uses a YG brand full hydraulic core drilling rig for detailed geological surveys, effectively avoiding engineering risks brought about by complex geological conditions and ensuring the safe and stable construction of bridges. ]
- Hydrogeological survey: In water resource exploration, groundwater resource evaluation, and water supply well construction, can be used for a hydrogeological survey to find out the groundwater storage conditions, water quantity, and water quality, and provide a scientific basis for water resource development and utilization. [Case: A drinking water source exploration project in a certain area successfully drilled out high-quality groundwater using a YG brand full hydraulic core drilling rig, effectively solving the drinking water problem of residents and improving people’s livelihood.]
4 FAQs About Full Hydraulic Core Drilling Rig:
FAQ 1: What exactly is a full hydraulic core drilling rig and what are its main uses?
A full hydraulic core drilling rig is a powerful piece of machinery designed to extract cylindrical samples of rock, known as cores, from the earth’s subsurface. This equipment is crucial for various industries. It’s primarily used in geological exploration to assess mineral deposits, in mining to guide extraction processes, and in construction to analyze ground conditions before building.
FAQ 2: What advantages does a full hydraulic core drilling rig offer compared to other drilling methods?
A full hydraulic core drilling rig stands out due to its superior power and control, both derived from its hydraulic system. This results in more efficient and faster drilling operations, greater stability during use, and enhanced precision in extracting core samples.
FAQ 3: Is YG Brand’s full hydraulic core drilling rig suitable for drilling through various rock formations?
Absolutely! YG Brand’s core drilling rig is designed for versatility. It’s capable of effectively drilling through a wide range of geological formations, from hard rock to softer, more fractured ground. The adjustable hydraulic power and the use of specialized drill bits ensure optimal performance across diverse rock types.
FAQ 4: Is YG Brand the actual manufacturer of the full hydraulic core drilling rig, or just a distributor?
YG Brand is a leading manufacturer specializing in the production of high-quality drilling equipment. By choosing YG Brand, you are buying directly from the factory. This direct sourcing guarantees product quality control throughout the manufacturing process and allows us to offer competitive, factory-direct pricing.
