A diesel concrete mixer is a concrete mixing equipment that uses a diesel engine as a power source. Compared with other types of mixers, it does not need to rely on an external power source and has greater mobility, making it particularly suitable for use in remote areas or construction sites with unstable power supplies. Whether it is a small civil construction project or a large infrastructure construction project, a diesel concrete mixer can play an important role. Contact us to get the diesel concrete mixer machine price now.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
Diesel Concrete Mixer Machine Parameter:
| Model | YG350 | YG400 | YG500 | YG750 | |
|
Working performance |
Discharge capacity | 350L | 400L | 500L | 750L |
| Feed capacity | 560L | 650L | 800L | 1200L | |
| Productivity | 10-14m3/h | 18-28m3/h | 14-18m3/h | 20-22m3/h | |
| Speed | 14r/min | 14r/min | 13r/min | 13r/min | |
| Maximum aggregate size | 60mm | 60mm | 60-80mm | 60-80mm | |
| Motor | Stirring motor | 5.5KW | 7.5KW | 11KW | 15KW |
| listing motor | 5.5KW | 7.5KW | 5.5KW | 7.5KW | |
| Pump motor | 0.55KW | 0.75KW | 0.75KW | 1.1KW | |
| Dimension | 2766*2140*3000mm | 3850*2200* 2850mm | 5226*2200* 5460mm | 6116*2056* 6060mm | |
| Total weight | 1950kg | 1950kg | 3100kg | 4200kg | |
Working Principle of Diesel Concrete Mixer
- Power transmission: After the diesel engine is started, the power is transmitted to the mixing drum/mixing drum through the transmission system (such as gears or belts).
- Material mixing: The mixing drum/mixing drum rotates under the power drive, and the mixing blades in the drum continuously flip and mix the concrete materials (cement, sand, gravel, water, etc.).
- Gravity/forced mixing: The drum mixer mainly relies on the rotation of the drum and the gravity of the material for mixing; the forced mixer relies on the forced shearing, squeezing, and flipping of the mixing blades to achieve more efficient mixing.
- Discharging process: After mixing is completed, the mixed concrete is discharged by operating the discharging mechanism (such as tilting the drum or opening the discharge port).
Advantages of Diesel Concrete Mixers:
- Strong independence: No external power supply is required, only diesel is used as fuel, and it can work independently in any place, especially suitable for field construction and areas with power shortage.
- High reliability: The diesel engine technology is mature and the performance is stable and reliable, which ensures the long-term stable operation of the mixer and reduces the shutdown delay caused by equipment failure.
- Easy operation: The diesel concrete mixer is relatively simple to operate and easy to use. The technical requirements for operators are low, which reduces labor costs.
- Wide applicability: It can adapt to various harsh working environments, such as high temperature, low temperature, dust, etc., and has a wide range of applications.
- Good mobility (some models): The diesel concrete mixer equipped with a walking mechanism is easy and flexible to move and can be quickly transferred to different work locations to improve work efficiency.
Wide Application Areas of Diesel Concrete Mixers:
- Construction projects in rural and remote areas: In rural areas with imperfect power infrastructure, diesel concrete mixers are the preferred equipment for small construction projects, such as residential housing construction and rural road construction.
- Road and bridge construction: At the construction site of outdoor roads and bridges, diesel concrete mixers can provide on-site concrete mixing to ensure the progress of the project.
- Water conservancy projects: The construction of water conservancy projects such as dams, levees, and canals often needs to be carried out in the field far away from the city center, and diesel concrete mixers can meet their concrete mixing needs.
- Mine construction: In mine construction projects, diesel concrete mixers can be used for concrete pouring operations such as mine tunnel support and ground construction.
- Emergency rescue projects: After a natural disaster, diesel concrete mixers can be quickly put into use to provide concrete guarantees for the reconstruction of disaster areas.
Diesel Concrete Mixer Machine Price in YG Machinery
In the construction industry, concrete mixers are indispensable equipment, and diesel concrete mixers have attracted much attention due to their unique advantages. YG Machinery’s mixers have been sold to Jamaica, the United States, Thailand, Georgia, South Korea, Malaysia, Australia and many other countries. Contact us for more information.【WhatsApp/WeChat/Phone/Skype】+86 136 1385 6800
